Yealink SkySound CS10 Ceiling Microphone Dubai

The Yealink SkySound CS10 Dubai is a standout choice in the realm of audio technology, boasting a discreet 2-way coaxial network speaker that has garnered acclaim for its exceptional performance, particularly in the realm of video conferencing. Its prowess lies in delivering top-notch audio quality tailored for the demands of modern meeting spaces. Crafted with a keen eye for contemporary aesthetics, the CS10 seamlessly marries high-fidelity sound with a sleek, minimalist design, making it the perfect complement to today’s cutting-edge conference rooms.Engineered with versatility in mind, this speaker is powered by Power over Ethernet (PoE) technology, offering not only superb sound quality but also flexible deployment options. Its compatibility with a range of supplementary components ensures easy installation across a variety of ceiling types, providing a hassle-free setup experience.

More than just a speaker, the Yealink SkySound CS10 Dubai is a refined addition to any meeting environment, elevating both the auditory and visual aspects of your conferencing space. Its sleek design and advanced features exude sophistication and technological prowess, making it the quintessential choice for professionals seeking the pinnacle of audio solutions.

In addition to its practicality, the CS10 serves as a statement piece, embodying elegance and innovation in equal measure. With its seamless integration into modern workplaces, it stands as a testament to the fusion of form and function in audio technology, setting a new standard for professional audio solutions in the digital age.

Key Features

Innovative Coaxial Structure: Equipped with a 2-way coaxial setup comprising a robust 5.7-inch LF Woofer and a distinctive 1.1-inch HF Tweeter, this speaker ensures precise audio reproduction.

High Performance Acoustics: Demonstrating outstanding acoustic properties, it boasts an 88-decibel sensitivity at 1 watt per meter and achieves a maximum sound pressure level of 99 decibels at 20 watts per meter, ensuring accurate and powerful audio performance.

PoE Enabled Active Speaker: The SkySound CS10 seamlessly merges advanced active speaker functionalities with a built-in DAC and PoE technology, facilitating effortless integration. This unique combination enables swift digital signal processing from the network, simplifying setup with minimal latency, ideal for diverse professional environments.

Dante Ready for Advanced Audio Networking:  Offered in two variants: one featuring Dante compatibility and the other as a standard model, the SkySound CS10 effortlessly integrates into sophisticated audio networks, providing flexibility for complex configurations and full compatibility with Dante audio systems. Choose the Dante-enabled option to leverage its enhanced audio networking capabilities.

Versatile Deployment:  With a variety of indoor installation options compatible with different ceiling types and grid systems, this speaker ensures smooth integration with any interior design scheme.

Sophisticated Design: Complete with a detachable magnetic grille, customizable to match your aesthetic preferences and available in black or white, the grille complements the speaker’s sleek design, measuring 120 mm to harmonize well with various modern interiors.

Specifications

Package Content

• SkySound CS10 Speaker
• White Mesh Cover (Black Optional)
• Quick Star t Guide
• Assembly Fixing Bracket
• Dust Cover
• Deployment Instruction Template
• Bracing Bridge (Optional)
• Dust Cover Screw*6 (M3*4CMHOZN3)

Audio Specifications

• Frequency Response (6dB): 10020kHz
• Maximum SPL:
  • Continuous: 99dB @20W 1m
  • Sensitivity: 88dB@1m 1W

Speaker Specification

• LF: 5.7inch (145 mm) woofer
• HF: 1.1inch (28 mm) tweeter
• Nominal Impedance: 8Ω
• Nominal Coverage Angle: 120

Product Specifications

• Size:
  • ф294*H125.8mm (with cover mesh）
  • ф2*H125mm (without cover mesh)
• Weight:
  • 2808g (without cover mesh) ；
  • 207g (Cover mesh)
• Product Color: white/black
• Cover Mesh Color: white/black
• Product Materials:
  • Cover Mesh: PC/ABS Welded SPCC
  • Main Body Shell: PA (Polyamide) with 15% GF
  • Bottom Shell: aluminum alloy
  • Cover Plate: PC/ABS and SGCC
  • Plenum Rated UL 2043 (suitable for air handling spaces)

Physical Specifications

• Operating Temperature: 050℃
• Storage Temperature: 050℃
• Operating Humidity: 5%~90%
• Peak Power: 20W
• Power Supply: PoE+ (IEEE 802.3at class 4)
• Interface: 1*RJ45

Logistic Information

• Canton Size: 398 mm*355 mm*185 mm
• W/CTN: 4.628 kg
• W/CTN: 5.597 kg
