Description
Ubiquiti UniFi USW-Lite-16-PoE Dubai
The UniFi Switch Lite 16 PoE is a fully managed Layer 2 switch with sixteen Gigabit Ethernet ports for your RJ45 Ethernet devices.
Eight ports also offer auto-sensing 802.3at PoE+ that provide up to a total PoE wattage of 45W for UniFi Access Points or other PoE devices.
Managed and configured by the UniFi Network application with UniFi mobile app support, the UniFi Switch Lite 16 PoE offers Layer 2 switching protocols and features. The UniFi Network application and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
Grow your network capacity to support computers, printers, storage, and power over Ethernet devices with the UniFi Lite 16-Port Gigabit PoE+ Compliant Managed Switch from Ubiquiti Networks. Featuring a 16 Gb/s switching capacity, this Layer 2 managed switch features 16 Gigabit Ethernet ports, eight of which are 802.3af/at PoE+ complaint with a 45W power budget, up to 30W per port, to operate compatible devices such as security cameras, VoIP phones, access points, and more. Network traffic with connected devices can be further optimized using the UniFi Network Controller, which offers a comprehensive suite of features to configure, control, and monitor performance. Additionally, its fanless design helps the switch to operate silently in the background of your home office or business. For added convenience, this desktop switch includes a wall mounting kit.
USW-Lite-16-PoE Switch key features
- 16 Gigabit RJ45 ports including eight 802.3at PoE+ ports
- Managed by UniFi Controller
- 60W power supply
- Wall-mountable (Kit included)
Ubiquiti USW-Lite-16-PoE – Technical Specs
| Mechanical | |
|---|---|
| Dimensions | 191.7 x 185 x 43.7 mm (7.55 x 7.28 x 1.72″) |
| Weight | 1.2 kg (2.65 lb) |
| Hardware | |
| Total Non-Blocking Line Rate | 16 Gbps |
| Max. Power Consumption | 15W |
| Power Method | Universal AC Input: 100-240VAC |
| Power Supply | Internal 60W AC/DC Power Supply |
| Networking Interfaces | (16) 10/100/1000 Mbps Ethernet RJ45 |
| PoE Interfaces | (8) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) |
| Mangement Interface | Ethernet In-Band |
| Max PoE+ Wattage per Port by PSE | 30W |
| Modes | SMB Layer 2 PoE Gigabit Ethernet Switch |
| Operating Temperature | -15 to 40° C (5 to 104° F) |
| Operating Humidity | 10 – 90% Noncondensing |
| Certifcations | CE, FCC, IC |
| LED | |
| System | (1) Power, Blue/White Flashing White: Bootup in Progress Flashing Blue: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted |
| Ethernet | Green: 1G, Amber: 10/100 Mbps |
| PoE | Amber: IEEE 802.3af/at |
