Description
Ubiquiti AirFiber60HD Wi-Fi Bridge Dubai
The Ubiquiti AirFiber60HD Dubai is a 60 GHz radio designed to create superior mid-range, point-to-point (PtP) links up to 2 km. The AF60 HD delivers low-interference, low-latency throughput within the 60 GHz spectrum. Compact and highly durable, the Ubiquiti AirFiber60HD Dubai also features integrated GPS and a Bluetooth management radio to simplify setup, configuration, and monitoring. This bridge is ideal for ISPs looking to maximize signal linking with cost-effective equipment.
Key Features:
- 60 GHz radio with 5 GHz radio backup
- Low-interference 60 Ghz spectrum
- Long range, up to 2 km
- Up to 1 Gbps with low latency
- Integrated GPS
- Full and half bandwidth support
Technical Specifications
General
- Dimensions : 413 x 413 x 320 mm (16.26 x 16.26 x 12.60″)
- Weight :
– Without Mount : 1.4 kg (3.09 lb)
– With Mount : 1.8 kg (3.97 lb) - Enclosure : Aluminum, UV-stabilised Polycarbonate
- Antenna Gain :
– 5 GHz : 11 dBi
– 60 GHz : 38 dBi - Networking Interface : (1) 10/100/1000 Mbps Ethernet Port
- Max. Power Consumption : 11W
- Power Method : Passive PoE, Pins 4, 5+ and 7, 8-
- Power Supply : 24VDC, 0.5A Gigabit PoE Adapter (Included)
- Voltage Range : +22 to +26VDC
- LEDs : Power/Ethernet/5G/60G/GPS
- Mounting : Pole Mount (Included)
- Wind Loading : 420 N @ 200 km/h (94.4 lbf @ 125 mph)
- Wind Survivability : 200 km/h (125 mph)
- ESD/EMP Protection : ± 24kV Contact/Air
- Operating Temperature : -40 to 60° C (-40 to 140° F)
- Operating Humidity : 5 to 95% Noncondensing
- Certifications : FCC, IC, CE
System
- Maximum Throughput : 1.8 Gbps
- Maximum Range : 2+ km
- Encryption : WPA2-PSK (AES)/WPA2 Enterprise
- OS : airOS GP
Radio
- Max. Conducted TX Power:
– 5/60 GHz Combined : 25 dBm - Channel Bandwidth :
– 60 GHz : 2160 MHz
– 5 GHz : 20/40/80 MHz
Operating Frequency (MHz)
- US/CA :
– U-NII-1: 5150 – 5250
– U-NII-3: 5725 – 5850
57,000 – 66,000
