Description
Tplink CPE210 Outdoor Radio Dubai
Whether using this device as a point to multi-point link or as an access point, the Tplink CPE210 Dubai 2.4 GHz N-300 9 dBi Outdoor Customer-Premises Equipment from TP-Link is capable of enhancing network performance and coverage. This CPE features a weatherproof enclosure complete with 15 KV ESD protection and 6,000 V lightning protection allowing it to withstand some of the harshest weather conditions.
The enclosure of the Tplink CPE210 Dubai is composed of outdoor ASA stabilized plastic and carries the IPX5 waterproof certification. Underneath the sturdy shell you will find one Fast Ethernet Passive PoE input eliminating the need for an additional PoE adapter. You will also find one grounding terminal for added protection against lightning strikes.
Once installed, you can take advantage of IEEE 802.11b/g/n networking standards to connect nearly any Wi-Fi enabled device to the Internet. The Tplink CPE210 Dubai operates on the 2.4 GHz routing frequency supporting a maximum data transfer rate of up to 300 Mbps with a transmit power of up to 27 dBm. Configure the CPE to suit nearly any networking need with support for AP, client, bridge, repeater, AP router mode, and AP client (WISP client) operation modes.
Features
- Tplink CPE210 Dubai has built-in 9 dBi 2×2 dual-polarized directional MIMO antenna
- Adjustable transmission power from 0 to 27 dBm / 500 mw
- System-level optimizations for more than 9 mi+ (15 km+) long range wireless transmission
- TP-LINK Pharos MAXtream (Time-Division-Multiple-Access) technology improves product throughput, capacity and latency performance, ideal for PTMP applications
- Tplink CPE210 Dubai is integrated with a centralized Management System – Pharos Control
- AP / Client / Repeater / Bridge / AP Router / AP Client Router (WISP) operation modes
- Passive PoE Adapter supports up to 200 feet (60 meter) Power over Ethernet deployment and allows the device to be reset remotely
Technical Specs
Wireless | |
Wireless Frequency Bands | 2.4 GHz Single-Band |
Number of Antennas | 1 |
MU-MIMO Support | 2 x 2 |
WLAN Mode | Wi-Fi 4 (802.11n) |
Sensitivity | -76 to -96 dBm |
Antenna Gain | 9 dBi |
Transmit Power | 26 to 27 dBm |
Supported Protocols |
|
Antenna Placement | Internal |
Performance | |
Throughput | 300 Mb/s Total 2.4 GHz : 300 Mb/s |
Interface | |
Ports | 1 x 10/100 Mb/s Ethernet (RJ45) PoE (Type 1) |
USB Sharing Support | No |
Security | |
Guest Network Support | No |
Wireless Security | WEP, WPA, WPA2 |
VPN Protocol | None |
Firewall Support | None |
Hardware | |
RAM | 64 MB |
Storage Capacity | 8 MB |
Supported IEEE Standards | 802.11b, 802.11g, 802.11n |
Electrical | |
DC Input Power | 16 to 27 VDC |
Power Consumption | 10.5 W |
Environmental | |
Operating Temperature | -22 to 158°F / -30 to 70°C |
Storage Temperature | -40 to 158°F / -40 to 70°C |
Operating Humidity | 10 to 90% |
Storage Humidity | 5 to 95% |
General | |
IP Rating | IPX5 |
Certifications | FCC *as per Manufacturer |
Dimensions | 8.8 x 3.1 x 2.4″ / 224 x 79 x 60 mm |
Packaging Info | |
Package Weight | 1.67 lb |
Box Dimensions (LxWxH) | 10.7 x 5.3 x 4.15″ |
