ThinkSystem SR570 Rack Server Dubai
The Lenovo ThinkSystem SR570 Dubai is a powerful yet cost-efficient 1U rack server, offering high performance and flexibility for businesses of all sizes, from small enterprises to large corporations. Designed to handle demanding workloads such as virtualization, cloud computing, infrastructure security, web hosting, and application development, this 2-socket server is a reliable choice for organizations looking for scalability, efficiency, and security.
Powered by the Intel Xeon Scalable Processor Gen 2, the SR570 server delivers exceptional computing power with up to 2.75TB memory capacity and support for NVMe PCIe SSDs, SAS/SATA SSDs, and HDDs. Its innovative AnyBay design allows for maximum storage flexibility, enabling businesses to mix and match different drive types in the same bay. With onboard NVMe PCIe ports, users can connect U.2 NVMe SSDs directly, freeing up PCIe slots and reducing storage acquisition costs.
Equipped with Lenovo XClarity Controller, the ThinkSystem SR570 provides simplified management, advanced monitoring, and serviceability features, ensuring seamless operation and reduced downtime. The server supports ASHRAE A4 standards, operating efficiently in high-temperature environments up to 45°C (113°F), which helps businesses lower energy consumption and operational costs.
Ideal for enterprises seeking a reliable, high-performance, and cost-effective rack server, the ThinkSystem SR570 Dubai strikes the perfect balance between processing power, storage flexibility, and security. With industry-leading reliability, built-in redundancy, and enterprise-grade management tools, it is an excellent choice for businesses aiming to optimize their IT infrastructure while maintaining efficiency and scalability.
Key Features
Workload-optimized support
Intel® Optane™ DC Persistent Memory delivers a new, flexible tier of memory designed specifically for data center workloads that offers an unprecedented combination of high-capacity, affordability, and persistence. This technology will have a significant impact on real-world data center operations: reduction of restart times from minutes down to seconds, 1.2x virtual machine density, dramatically improved data replication with 14x lower latency and 14x higher IOPS, and greater security for persistent data built into hardware
Flexible storage
Lenovo AnyBay design features a choice of drive interface type in the same drive bay: SAS drives, SATA drives, or U.2 NVMe PCIe drives. Freedom to configure some of the bays with PCIe SSDs and still use the remaining bays for capacity SAS drives provides the ability to upgrade to more PCIe SSDs in the future as needed.
Technical Specifications
Form Factor | 1U |
Processor | Up to 2 second-generation Intel® Xeon® Platinum 150W, up to 26 cores per CPU |
Memory | Up to 1TB of 2933MHz TruDDR4 in 16 slots, Intel® Optane™ DC Persistent Memory |
Expansion Slots | Up to 3 PCIe 3.0 |
Drive Bays | Up to 10x 2.5″ (including optional 4x direct-connect AnyBay) or up to 4x 3.5″ |
Internal Storage | Up to: 48TB (3.5″ SAS/SATA HDD); 30.72TB (3.5″ SATA SSD); 24TB (2.5″ SAS/SATA HDD); 76.8TB (2.5″ SSD); 30.72TB (2.5″ NVMe); 1x or 2x M.2 |
Network Interface | 2 GbE ports standard; LOM interface standard; optional ML2, PCIe |
NIC Ports | 2x GbE standard; 1x GbE dedicated management standard |
Power | Up to 2x hot-swap/redundant 550W/750W Platinum, 750W Titanium |
High-Availability Features | Hot-swap HDDs/SSDs/NVMe, hot-swap PSUs and fans, light path diagnostics, PFA for all major components, ASHRAE A4 support (with limits), optional XClarity Pro with Call Home feature |
RAID Support | HW RAID 0, 1, 5 standard on hot-swap models; SW RAID 0, 1, 5 on simple-swap 3.5″ models |
Security | Lenovo ThinkShield, locking bezel; locking top cover; TPM 2.1 standard; optional TCM (China only) |
Management | XClarity Administrator; XClarity Controller (embedded hardware); optional XClarity Pro |
OS Support | Microsoft, SUSE, Red Hat, VMware. |
Limited Warranty | 1- and 3-year customer replaceable unit and onsite service, next business day 9×5 |
