Description
Qnap TS-569 Pro Dubai
The for SMBs from QNAP is an all-in-one NAS server with exceptional performance that can meet the storage requirements of modern SMB IT environments. It features a secure cross-platform file sharing for Windows, Mac and Linux/UNIX users. The NAS server also It has a well-rounded set of backup solutions, which helps critical business information to be safely protected against unexpected data loss. The NAS server is an ideal shared storage solution for virtualized and clustered environments. It is VMware-ready and Citrix-ready certified. This also has proven compatibility with Microsoft Hyper-V environments.
The intuitive MyCloudNAS service simplifies the process of publishing content present on the Turbo NAS over the Internet and helps you create a private cloud in a few simple steps. The mobile app QMobile provides iOS or Android mobile device users with a convenient way to access the Turbo NAS live, on the go.
Deploying an appropriate IT environment with a reliable, affordable and expandable storage solution is very critical for any business. The ability to securely store, share and back-up digital assets has become one of the most important tasks for an SMB IT administrator. Choosing the right option will significantly enhance business productivity and offer a reliable disaster recovery solution in today’s times, when downtime of any type affects profitability. The Qnap TS-569 Pro Dubai is an all-in-one server that meets the storage requirements of modern businesses and workgroups that face the challenge of finding a robust storage solution that can scale with the exponential increase in digital content.
Features:
Cross-platform Sharing with Antivirus
Windows Active Directory (AD) and LDAP Directory Service
Shared Folder Aggregation
ISO File Archiving and Sharing
Advanced Folder Permissions
Secure Measures for Data Storage and Access
You can allow, deny or auto block specified IP address or network domain which attempt to connect to the Turbo NAS via SSH, Telnet, HTTP(S), FTP, Samba or AFP.
QNAP TS-569 Pro Specs
| Hardware | |
| CPU | Intel Atom 2.13 GHz Dual-Core Processor |
| DRAM | 1 GB RAM (expandable RAM, up to 3 GB) |
| Flash Memory | 512 MB DOM |
| Hard Drive | 5x 3.5″ (88.89 mm) SATA 6 GBps, SATA 3 GBps hard drive or 2.5″ (63.49 mm) SATA, SSD hard drive |
| Hard Disk Tray | 5x hot-swappable and lockable tray |
| LAN Port | 2x Gigabit RJ-45 Ethernet ports |
| LED Indicators | Status, LAN, USB, eSATA, Power, HDD 1, HDD 2, HDD 3, HDD 4, HDD 5 |
| USB | 2x USB 3.0 ports (back: 2) 5x USB 2.0 ports (front: 1 ; back: 4) Supports USB printer, pen drive, USB hub, USB UPS and more |
| eSATA | 2x eSATA ports (back) |
| Performance | Reading: 221.8 MBps Writing: 220.8 MBps |
| Buttons | System: Power button, USB one touch backup button and reset button |
| LCD Panel | Mono-LCD display with backlight Enter and select buttons for configuration |
| Supply Type | System warning |
| Form Factor | Tower |
| Sound Level | Without HDD installed: 34.3 dB Stand by: 34.3 dB In operation: 35.0 dB (with 5x 500GB HDD installed) |
| Power Consumption | Sleep mode: 29.1 W In operation: 48.5 W Power-off (in WOL mode): 1 W (with 500GB HDD installed) |
| Power Supply | Input: 100 – 240 V AC, 50 – 60 Hz Output: 250 W |
| Secure Design | K-lock security slot for theft prevention |
| VGA | Reserved VGA interface for maintenance |
| Fan | 1x 4.72″ (12 cm), 12 V DC quiet cooling fan |
| Software | |
| Operating System | Embedded Linux |
| Supported Operating System | Windows XP, Vista, Windows 7 (32/64-bit), Windows Server 2003/2008 R2 Apple Mac OS X Linux and UNIX |
| Supported Web Browsers | Microsoft Internet Explorer 8, 9 Mozilla Firefox 8, 9, 10 Apple Safari 4, 5 Google Chrome |
| Language Support | Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish |
| File System | Internal Hard Drive: EXT3, EXT4 External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+ |
| Networking | TCP/IP (IPv4 and IPv6: Dual stack) Multiple Gigabit NICs with jumbo frame -Failover -Multi-IP settings -Port trunking/NIC teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb) Service binding based on network interfaces Virtual LAN (VLAN) DHCP client, DHCP server Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC UPnP and bonjour discovery USB Wi-Fi adapter support |
| Backup Solution | Real-Time Remote Replication (RTRR) -Works as both RTRR server and client with bandwidth control -Real-time and scheduled backup -Encryption, compression, file filter and transfer rate limitation Block-Level Remote Replication -Works as both Rsync Server and client with bandwidth control -Encrypted replication between QNAP NAS servers One touch backup (import/export) via USB Desktop backup by QNAP NetBak replicator for Windows Apple Time Machine support with backup management Data backup to multiple external storage devices Data backup to Cloud Storage (Amazon S3, ElephantDrive and Symform) |
| Security | IP Filter and policy-based automatic IP blocking Network access protection with auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), encrypted remote replication between QNAP NAS servers (Rsync over SSH) CIFS host access control for shared folders Antivirus protection FIPS 140-2 validated AES 256-bit volume-based data encryption* AES 256-bit external drive encryption* Importable SSL certificate Instant alert via Email, SMS, Instant Messaging (Windows Live), Beep and LCD panel |
| Disk Management | Single Disk, JBOD, RAID 0, 1, 5, 5+Hot-Spare, 6, 6+Hot-Spare, 10, 10+Hot-Spare Online RAID capacity expansion and online raid level migration Bad block scan and hard drive S.M.A.R.T. Global hot-spare drive RAID recovery Bitmap support |
| iSCSI (IP SAN) | iSCSI target -Multi-LUNs per target -Up to 256 targets/LUNs combined -Supports LUN mapping and masking -Online LUN capacity expansion -Supports SPC-3 persistent reservation -Supports MPIO and MC/S iSCSI LUN backup, one-time snapshot and restore iSCSI connection and management by QNAP finder (Windows) Virtual disk drive (via iSCSI initiator) -Stack chaining master -Max. no. of virtual disk drives: 8 |
| Server Virtualization and Clustering | Supports VMware vSphere Supports Citrix XenServer Supports Windows Server 2008 R2 Hyper-V and failover clustering |
| Power Management | Wake on LAN Internal hard drive standby mode Scheduled power on/off (max. 15 Settings) Automatic power on after power recovery USB and network UPS support with SNMP management |
