Description
Qnap TS-221 Dubai
The Qnap TS-221 Dubai 2-Bay NAS Server is a powerful yet easy-to-use network storage center for data storage, backup, synchronization, remote access and home entertainment. As your personal cloud, you will always be connected to your files and your files are always under your control.
Key Features:
- Easier Operations on QTS 4.0 Desktop
- The QTS 4.0 Desktop, including quick Main menu, graphic dashboard, drag-and-drop icons, multiple desktops, personalized wallpapers and the smart toolbar, makes system operations much easier. In addition, multi-tasking is supported which allows multiple windows to be open to access multiple applications concurrently.
- Centralize and Protect Your Data
- The Qnap TS-221 Dubai is a high-performance cross-platform storage with many user-friendly storage and backup options to centralize and protect all your important files on one single device.
- Apple Time Machine Backup
- Time Machine is fully supported to help Mac OS X users create a more efficient and convenient backup solution. The Qnap TS-221 Dubai works with Time Machine wirelessly over the same network so you no longer need an external drive.
- More Backup Options
- Netbak Replicator is a license-free backup software which allows you to back up your files in multiple Window client PCs in schedule or real time. You can also gain a disaster recovery solution with our RTRR (Real Time Remote Replication) feature by replicating data in multiple shared folders from one NAS to another over the network to ensure safety of your important data. Besides, data can also be backed up to another FTP server, external disk or online cloud storage services.
- User Access Controls
- All your digital files stored can be managed to share with your family and friends. You can easily and flexibly set up user accounts, user groups, shared folder access right and user quota.
- Unauthorized IP-Based Blocking
- A comprehensive list granting proper access from different users based on IP address can be established to authorize or deny access to the Qnap TS-221 Dubai.
- Anti-Virus
- The Qnap TS-221 Dubai has a built in anti-virus feature to detect and protect against viruses, malware, worms and Trojan horses.
- Encrypted Login, Access and Network Transfer
- SSH remote login, SSL security (HTTPS), Secure FTP and encrypted remote replication are supported.
- Detailed Logs
- Detailed logs of file-level access to the TS-221 via different file transfer protocols and services accessed by online users can all be recorded.
- Freely Access Your Cloud Anywhere
- Through any web browser or the free app for tablets and smartphones, the Home and SOHO NAS becomes your personal cloud so you are always connected to your data. Take advantage of the myQNAPcloud service, which allows you to remotely access yourTS-221 wherever you are. Instantly stream or share your multimedia contents and share them with your friends.
- Access from Anywhere
- Qsync is a new feature that allows you to sync all your devices on the go. It can be synced literally anywhere–on the web, at your home, in the office and on the go. Qsync makes the server a team sharing device, allowing you to share and edit files among your teammates with automatic updates on the files your team is working on. Qsync provides the function of file synchronization like Dropbox service and brings forth a cost-effective way to share files across groups and communities.
Qnap TS-221 – Technical Specifications
Hardware Specifications
| CPU | Marvell 2.0 GHz |
| DRAM | 1 GB DDR3 RAM |
| Flash Memory | 16 MB |
| HDD | 2 x 3.5″ or 2.5″ SATA II HDD/SSD |
| HDD Tray | 2 x hot-swappable tray |
| LAN Port | 1 x Gigabit RJ-45 Ethernet port |
| LED Indicator | STATUS, LAN, USB, HDD 1, HDD 2 |
| USB | 1 x USB 2.0 port (Front); 2 x USB 3.0 port (Back) Supports USB printer, disk, pen drive, USB hub and USB UPS etc. |
| eSATA | 2 x eSATA port (Back) |
| Buttons | Power button, USB one-touch-backup button, reset button |
| Alarm Buzzer | System warning |
| Form Factor | Tower |
| Power Consumption | Sleep mode: 8 W In operation: 19 W (With 2 x 500 GB HDD installed) |
| Temperature | 32~104°F (0~40˚C) |
| Humidity | 0~95% R.H. |
| Sound Level | Sound Level (Standby/In Operation): 11.9 dB/ 25.3 dB |
| Power Supply | External power adaptor, 60 W, Input: 100-240 V |
| Secure Design | K-lock security slot for theft prevention |
| Fan | 1 x quiet cooling fan (7 cm, 12 V DC) |
Software Specification
| Operating System | QTS 4.0 |
| Supported Clients | Windows 8 (32/64-bit), Vista, Windows 7 (32/64-bit), Windows XP, Windows Server 2003/2008 R2/2012 Apple Mac OS X Linux and UNIX |
| Supported Browsers | Microsoft Internet Explorer 8, 9, 10 Mozilla Firefox 8+ Apple Safari 4+ Google Chrome |
| File System | Internal Hard Drive: EXT3, EXT4 External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+ |
| Networking | TCP/IP (IPv4 and IPv6: Dual Stack) Proxy Client, proxy server DHCP Client, DHCP Server Protocols: CIFS/SMB, AFP (v3.3), NFS (v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP and SMSC TFTP Server with PXE Booting UPnP & Bonjour Discovery USB Wi-Fi Adapter Support |
| Backup Solution | Real-time Remote Replication (RTRR) Works as both RTRR server and client with bandwidth control Real-time and scheduled backup Encryption, compression, file filter and transfer rate limitation Block-level remote replication Encrypted Replication between QNAP NAS Servers Desktop backup by QNAP NetBak Replicator for Windows Apple Time Machine support with backup management Data backup to multiple external storage devices Data backup to cloud storage (Amazon S3, ElephantDrive, Symform and Google Drive) |
| Security | IP Filter and Policy-based Automatic IP Blocking Network Access Protection with Auto-blocking: SSH, Telnet, HTTP (S), FTP, CIFS/SMB, AFP Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH) CIFS host access control for shared folders Antivirus protection Importable SSL certificate Instant alert via E-mail, SMS, instant messaging (Windows Live) and beep |
| Disk Management | Single Disk, JBOD, RAID 0, 1 Online RAID capacity expansion and online RAID level migration Bad block scan and hard drive S.M.A.R.T. RAID recovery Bitmap support |
| iSCSI (IP SAN) | iSCSI Target with Multiple LUNS per target (Up to 256 targets/LUNs combined) LUN mapping and masking Online LUN capacity expansion Supports SPC-3 persistent reservation Supports MPIO and MC/S iSCSI LUN backup, one-time snapshot and restore iSCSI connection and management by QNAP finder (Windows) Stack Chaining Master: Up to 8 virtual disk drives (via iSCSI initiator) |
| Server Virtualization and Clustering | Supports VMware vSphere (ESX/ESXi 4.x, ESXi 5.x) Supports Citrix XenServer 5.x, 6.x Supports Windows Server 2008 R2 and Windows Server 2012 Hyper-V Supports Windows Server 2008 R2 and Windows Server 2012 Failover Cluster |
| Power Management | Wake on LAN Internal hard drive standby mode Scheduled power on/off (max 15 settings) Automatic power on after power recovery USB and Network UPS support with SNMP management |
| Access Rights Management | Max No. of Users: 2,048 Max No. of User Groups: 256 Max No. of Network Shares: 256 Batch users creation Import/export users User quota management Local user access control for CIFS, AFP, FTP and WebDAV Application access control for Photo Station, Music Station and Video Station Subfolder permissions support for CIFS/SMB, AFP, FTP and File Station |
| Domain Authentication Integration | Microsoft Active Directory (AD) LDAP Server LDAP Client Domain Users Login via CIFS/SMB, AFP, FTP and Web File Manager |
| myQNAPcloud Service | Private cloud storage and sharing Free host name registration (DDNS) Auto router configuration (via UPnP) CloudLink for easy VPN connection (Windows VPN Utility) |
| Storage Plug and Play | Windows Software: QNAP finder Create and map shared folders Create and connect to iSCSI target/LUN |
| Web Administration | Smart fan control Dynamic DNS (DDNS), SNMP (v2 and v3), Resource Monitor Network Recycle Bin for File Deletion via CIFS/SMB and AFP Automatic cleanup, file type filter, comprehensive logs (events and connection) Syslog client, firmware live update, system settings backup and restore Restore to factory default, mobile app Qmanager for remote monitoring |
| Multilingual Support | Chinese (Traditional and Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish |
| Photo Station | Supported File Formats: Photo: JPG/JPEG, GIF, PNG, BMP, RAW (.arw, .srf, .sr2, .dcr, .kdc, .cr2, .crw, .nef, mrw, .pef, .paf, .3fr, .erf, .mef, .mos, .orf, .rw2, .dng, .x3f, .tif, .nrw, .raf) Video: FLV, MPEG-4 Video (H.264 + AAC)Image Slideshow with Background Music, Thumbnails and different transition effects online photo editing by Pixlr editor Geotagging photos with Google Maps Slideshow sharing (from private albums) with password protection Photo publishing to social websites (Facebook, MySpace, Twitter, Plurk and Blogger) Photo sharing by Email |
| File Station | File sharing across Windows, Mac and Linux/UNIX Windows ACL Advanced folder permission for SMB, AFP, FTP and File Station Shared folder aggregation (CIFS/SMB)file manager Supports ISO mounting (Up to 256 ISO files) File viewing via Google doc Create and send download links for public file sharing with expiration time and password protection File drag-n-drop via Chrome and Firefox browsers Photo, Music and Video Preview and Playback with Transcoding File Compression (ZIP or 7z) Advanced search Mobile App: Qfile for file browsing and management |
| Music Station | Supported Audio Formats: MP3, OGG, WAV, AIFF, AU, FLAC, M4A, APE, AACLocal playback with USB speakers/sound card Music streaming from DLNA/UPnP media servers Internet radio (MP3) Music alarm (up to 8 alarms) Remote playback control by QNAP mobile app: QMobile |
| FTP Server | FTP over SSL/TLS (explicit) Max no. of concurrent connections: 256 FXP supported Passive FTP port range control FTP bandwidth and connection control Unicode support |
| iTunes Server | Audio and video sharing for Windows and Mac iTunes (MP3, AIFF, WAV, MPEG-4, AAC and M4A) Smart Playlist |
| Backup Station | Remote replication server (over Rsync) Real-time remote replication to another QNAP NAS or FTP Server Apple time machine support Windows client backup application: QNAP NetBak Replicator Third party backup software support: Veeam Backup and Replication, Acronis True Image, ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper etc. |
| Video Station | Web video sharing Video categorization and transcoding Supported format: mv,avi,divx,3gp,mov, mpeg, mpg, xvid, flv, asf, rm, dat, mp4Video Upload: Up to 2048MB in size, up to 320 minutes in length, batch upload (max 50 files) Publish videos to Facebook, Twitter and Google+ |
| TV Station | DVB-T digital TV live view, recording and playback Supports up to 2 USB TV tuners Electronic programming guide (EPG) with scheduled recording |
| Print Server | Max No. of Printers: 3 Supports internet printing protocol Print job display and management IP-based and domain name-based privilege control Supports Apple bonjour printing |
| DJ Station | Live web broadcast of music playlists Music sharing on Facebook |
| VPN Server | Secure Remote Access: PPTP and openVPN VPN services Remote access to other resources on local network Max no. of clients: 30 |
| Download Station | PC-less BT, FTP and HTTP download (up to 500 tasks)
BT download with magnet link and PT support HTTP/FTP download RapidShare download support |
| Web Server | HTTP/HTTPS connections, supports WebDAV connection Supports Virtual Host (Max: 32), Importable SSL Certificate |
| Database Server | Built-in MySQL server, web-based management via phpMyAdmin (App Center) |
| Syslog Server | Centralized log monitoring and archiving, instant E-mail alerts Supports log filtering |
| RADIUS Server | Centralized account management and authentication for network access Supports PAP, EAP-TLS/PAP and EAPTTLS/PAP authentication |
| Surveillance Station Pro | Supports over 1,400 IP cameras, includes 1 free camera license Up to 8 camera channels via additional license purchase Intelligent Video Analytics (IVA) for advanced video search, visual aid by E-map Surveillance client for Mac, mobile app- VMobile (iOS and Android) |
| Antivirus | Protection against viruses, trojans and other threats Free virus databases update on manual or scheduled basis Multiple scan tasks (Max: 64, concurrent: 5) with custom folder selection and scheduled scanning Email notification upon task completion or virus detection Quarantines or deletes infected files |
Physical
| Dimensions | 4.02 x 5.91 x 8.5″ (102 x 150 x 216 mm) |
| Weight | 3.84 lb (1.74 kg) |
Packaging Info
| Box Dimensions (LxWxH) | 10.8 x 9.3 x 8.2″ |
