Technical Specifications

General

• Recommended Use Cases : Small branch
• Recommended Clients : 50
• Stateful Firewall Throughput : 450 Mbps
• Advanced Security Throughput : 300 Mbps
• Maximum VPN Throughput : 200 Mbps
• Maximum Concurrent VPN Tunnels : 50
• WAN Interfaces ( Dedicated) : 2 x GbE RJ45, 1 x USB (cellular failover )
• LAN Interfaces : Fixed 10 x GbE RJ45, ( 2 x PoE+)
• Mounting : Desktop or wall mount
• Dimensions : 11.2” x 5.8” x 1.1” (284mm x 148mm x 27mm)
• Weight : 2.46 lb (1.12 kg)
• Power Supply : 100W DC
• Operating Temperature : 32°F to 104°F (0°C to 40°C)
• Humidity : 5% to 95%

Management

• Managed via the web using the Cisco Meraki dashboard
• Single-pane-of-glass into managing wired and wireless networks
• Zero-touch remote deployment (no staging needed)
• Automatic firmware upgrades and security patches
• Templates based multi-network management
• Org-level two-factor authentication and single sign-on
• Role-based administration with change logging and alerts

Monitoring and Reporting

• Throughput, connectivity monitoring and email alerts
• Detailed historical per-port and per-client usage statistics
• Application usage statistics
• Org-level change logs for compliance and change management
• VPN tunnel and latency monitoring
• Network asset discovery and user identification
• Periodic emails with key utilization metrics
• Device performance and utilization reporting
• Netflow support
• Syslog integration

Remote Diagnostics

• Live remote packet capture
• Real-time diagnostic and troubleshooting tools
• Aggregated event logs with instant search

Network and Firewall Services

• Stateful firewall, 1:1 NAT, DMZ
• Identity-based policies
• Auto VPN: Automated site-to-site (IPsec) VPN, for hub-and-spoke or mesh topologies
• Client (IPsec L2TP) VPN
• Multiple WAN IP, PPPoE, NAT
• VLAN support and DHCP services
• Static routing
• User and device quarantine

WAN Performance Management

• Web caching (available on the MX84, MX100, MX250, MX450)
• WAN link aggregation
• Automatic Layer 3 failover (including VPN connections)
• 3G / 4G USB modem failover or single-uplink
• Application level (Layer 7) traffic analysis and shaping
• Ability to choose WAN uplink based on traffic type
• SD-WAN: Dual active VPN with policy-based routing and dynamic path selection
• CAT 6 LTE modem for failover or single-uplink1

Advanced Security Services

• Content filtering (Webroot BrightCloud CIPA compliant URL database)
• Web search filtering (including Google / Bing SafeSearch)
• YouTube for Schools
• Intrusion-prevention sensor (Cisco SNORT® based)
• Advanced Malware Protection (AMP)
• AMP Threat Grid
• Geography-based firewall rules (MaxMind Geo-IP database)

Integrated Cellular

• LTE bands : 2, 4, 5, 12, 13, 17, and 19 (North America). 1, 3, 5, 7, 8, 20, 26, 28A, 28B, 34, 38, 39, 40, and 41 (Worldwide)
• 300 Mbps CAT 6 LTE
• Additional regulatory information : PTCRB (US), RCM (ANZ, APAC), GCF (EU)

Regulatory

• FCC (US)
• CB (IEC)
• CISPR (Australia/New Zealand)
• PTCRB (US)
• RCM (Australia/New Zealand, Asia Pacific)
• GCF (EU)

Warranty

• Full lifetime hardware warranty with next-day advanced replacement included.
