Description
FortiWifi30G Next-Generation Firewall Dubai
The FortiWifi30G Dubai is a comprehensive solution that combines firewall, SD-WAN, and security into a single, integrated appliance. It is ideal for enterprises looking to establish security-driven networks across distributed locations while optimizing WAN architecture at any scale. Powered by FortiOS, the industry’s first operating system to converge networking and security, this platform allows businesses to effectively safeguard their dynamic digital infrastructures. As a key component of the FortiWifi30G Security Fabric platform, the FortiWifi30G Next-Generation Firewall (NGFW) seamlessly integrates with FortiGuard AI-powered Security Services, delivering automated, real-time, end-to-end threat protection across diverse use cases.
The FortiWifi30G is engineered with a patented SD-WAN ASIC, offering superior performance compared to traditional CPU-based systems, while also reducing costs and power consumption. Its application-specific design and embedded multi-core processor further enhance the convergence of networking and security, ensuring secure and optimized connections at branch locations.
Key features of the FortiWifi30G Dubai include a built-in Next-Generation Firewall (NGFW) that provides robust protection against cyber threats such as malware, viruses, spyware, and botnets. To ensure high-speed performance, the device supports Wi-Fi 6 standards, delivering faster and more reliable wireless connectivity. Its dual-band capability, operating on both 2.4 GHz and 5 GHz frequencies, enhances performance and coverage, while beamforming technology focuses Wi-Fi signals toward specific devices for improved range and efficiency. Additionally, MU-MIMO technology allows multiple devices to connect simultaneously without compromising speed. The FortiWifi30G offers centralized management through the FortiCloud platform and features an intuitive, web-based interface for simplified configuration and administration.
Specifications:
Hardware Specifications | |
Hardware Accelerated GE WAN Port | 1 |
Hardware Accelerated GE RJ45 Ports | 2 |
Hardware Accelerated GE RJ45 FortiLink Port (Default) | 1 |
USB Ports | — |
Console Port (RJ45) | 1 |
Trusted Platform Module (TPM) | |
Bluetooth Low Energy (BLE) | — |
Wireless Interface | Dual Radio (2.4 GHz/ 5 GHz), 802.11 a/b/g/n/ac/ax |
System Performance* — Enterprise Traffic Mix | |
IPS Throughput | 800 Mbps |
NGFW Throughput | 570 Mbps |
Threat Protection Throughput | 500 Mbps |
System Performance | |
IPv4 Firewall Throughput (1518 / 512 / 64 byte, UDP) |
4/ 4/ 3.9 Gbps |
IPv6 Firewall Throughput (1518 / 512 / 86 byte, UDP) |
4/ 4/ 3.9 Gbps |
Firewall Latency (64 byte UDP packets) |
2.87 μs |
Firewall Throughput (Packets Per Second) |
5.85 Mpps |
Concurrent Sessions (TCP) | 600,000 |
New Sessions/Second (TCP) | 30,000 |
Firewall Policies | 2000 |
IPsec VPN Throughput (512 byte) | 3.5 Gbps |
Gateway-to-Gateway IPsec VPN Tunnels | 200 |
Client-to-Gateway IPsec VPN Tunnels | 250 |
SSL-VPN Throughput | — |
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) |
— |
SSL Inspection Throughput (IPS, avg. HTTPS) |
400 Mbps |
SSL Inspection CPS (IPS, avg. HTTPS) | 260 |
SSL Inspection Concurrent Session (IPS, avg. HTTPS)3 | 55,000 |
Application Control Throughput (HTTP 64K) | 830 Mbps |
CAPWAP Throughput (HTTP 64K) | TBA Gbps |
Virtual Domains (Default / Maximum) | Not Supported |
Maximum Number of FortiSwitches Supported | 8 |
Maximum Number of FortiAPs (Total / Tunnel Mode) | 16/8 |
Maximum Number of FortiTokens | 500 |
High Availability Configurations | Active-Passive, Active-Active |
Dimensions | |
Height x Width x Length (inches) | 1.6 x 5.6 x 6.3 |
Height x Width x Length (mm) | 40.5 x 142 x 160 |
Weight | 1.5 lbs (0.7 kg) |
Rack Mount Type | NA |
Wall Mountable | Optional |
Form Factor (supports EIA/non‑EIA standards) | Desktop |
Operating Environment and Certifications | |
Power Rating | 12VDC, 2A |
Power Source Powered by external DC power adapter | 100-240V AC, 50/60 Hz |
Maximum Current | 110V/0.17A, 240V/0.085A |
Power Consumption (Average / Maximum) | 11.3 W / 13.6 W |
Heat Dissipation | 46 BTU/hr |
Operating Temperature | 32° to 104°F (0° to 40°C) |
Storage Temperature | -31° to 158°F (-35° to 70°C) |
Humidity | 20% to 90% non-condensing |
Noise Level | N/A |
Operating Altitude | 10 000 ft (3048 m) |
Compliance | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA |
Certifications | USGv6/IPv6 |
