Description

Flyingvoice FGW4148-32S FXS VoIP Gateway Dubai

Flyingvoice FGW4148-32S VoIP Gateway Dubai which has 32 FXS ports, one LAN port, and one WAN port, is one among the foremost popular VoIP gateway researched and produced by Flyingvoice. This product can’t only provide 32 SIP lines for users to form calls, but also it’s a wire-speed NAT router, cause you to enjoy an easy network atmosphere. What’s more, FGW4148-32S supports T.38 real-time FAX and T.30 FAX with G.711.Flyingvoice FGW4148-32S VoIP FXS Gateway Dubai is a stand-alone device, which needs no PC to create Internet calls. This gateway guarantees clear and reliable voice quality on the Internet, which is fully compatible with the SIP industry standard and able to interoperate with many other SIP devices and software on the market. The Flyingvoice FGW4148-32S VoIP Gateway Dubai products in Flyingvoice, which enables customers to register to a different register to different SIP Proxy server, IP PBX and establish up to several concurrent VoIP incorporate more flexibility within the oral communication.they excellent voice quality, packed feature functionality and best-in-class price-performance point enable consumers to maximize the ability of IP voice and data connectivity.

Flyingvoice FGW4148-32S FXS VoIP Gateway Features :

• 10/100/1000Mbps Ethernet
• 32 FXS Port
• Auto-provisioning- TFTP/HTTP/HTTPS
• Supports T.38 and T.30 Real-time Fax (G.711)

Flyingvoice FGW4148-32S FXS VoIP Gateway Specifications :

VoIP SoC : CPU:MT7621A

Flash: 32MB Flash

RAM: 256MB SDRAM

Operating System: Linux 2.6.36

Power

• AC/DC Adapter
• AC Input: 100~240V, 50~60Hz

I/O Interfaces

• 1 RJ-45 for WAN port (Ethernet 1000 Base-T)
• 1 RJ-45 for LAN port (Ethernet 1000 Base-T)
• 32 RJ-11 for FXS ports

Environmental

• Operation Temperature: 0~50 Degree C
• Storage Temperature: -25~ 85 Degree C
• Relative Humidity: 10%~90% No Condensing

Audio Codec

• G.711(A/u),PESQ>4.3
• G.729AB,PESQ>3.7
• Adaptive Jitter Buffer Management
• Voice Activity Detection
• Comfort Noise Generation
• Echo Cancellation
• T.30 FAX with G.711
• Real time FAX over IP via T.38

Management

• Firmware Upgradeable
• Web Management Interface
• IVR-driven Management Interface
• Local and Remote Syslog (RFC3164)
• Auto Provisioning
• SNTP Time Synchronization
• Multi-User Level
• SNMPv2
• TR069
• Support Flying FCMS Cloud Management

Protocols

• SIP V2 (RFC 3261,3262,3263,3264)
• Backward Compatible with RFC2543
• Session Timer (RFC4028)
• SDP (RFC2327)
• RTP/RTCP (RFC1889 and RFC1890)
• NAPTR for SIP URI Lookup (RFC2915)
• STUN (RFC 3489)
• ARP/RARP (RFC 826/903)
• SNTP (RFC 2030)
• DHCP/PPPoE
• PPTP/L2TP VPN/ OpenVPN
• HTTP Server for Web Management
• TFTP/HTTP/HTTPS for Auto Provisioning
• DNS/DNS SRV (RFC1706 and RFC 2782)
• FGW4148 Specification

Applications

• NAT/NAPT Router function
• MAC Address Cloning
• DHCP Server
• PPTP/L2TP VPN
• PPPoE
• SIP proxy redundancy
• Dynamic via DNS SRV, A records
• NAT Traversal by STUN
• DMZ
• QoS with Layer 3
• DHCP Client and DHCP Server
• IP conflict detection

Call Features

• 3-Way Conference
• Music on hold
• DTMF mode: In-band, RFC2833 and SIP INFO
• Call Hold
• Call Forwarding
• Call Mute
• Call Transfer
• Call Waiting
• Speed Dial
• Caller ID and CWCID
• Hotline
• Dial Plan
• Black List
• Call Log
