Cisco WAP125 Access Point Dubai
The Cisco WAP125 Dubai is an entry-level access point that has been designed to serve the connectivity needs and requirements small businesses, home offices, and small offices that require fast, simple, and secure Wi-Fi connectivity at an affordable price.
The Cisco Wi-Fi Dubai is a powerful Wireless-AC Dual Band Desktop Access Point that comes equipped with PoE to provide a simple, cost-effective way to extend secure, high-performance mobile networking to your employees and guests, so they can stay connected anywhere in the office. Cisco WAP125 Dubai lets you connect dozens of employees, and can scale to accommodate additional users and changing business needs.
The Cisco WAP125 Dubai uses concurrent dual-band radios for improved coverage on mobile devices. A Gigabit Ethernet LAN interface with PoE supports flexible installation and can reduce cabling and wiring costs. Intelligent Quality-of-Service (QoS) features let you prioritize bandwidth-sensitive traffic for Voice over IP (VoIP) and video applications.
To provide highly secure guest access to visitors and other users, the Cisco Wi-Fi Dubai supports a captive portal with multiple authentication options and the ability to configure rights, roles, and bandwidth. A customized guest login page lets you present a welcome message and access details, and reinforces your brand with company logos.
The Cisco WAP125 Dubai is easy to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. An attractive, compact design with integrated stand allows the access point to be placed on a desk or other flat surface.
To enhance reliability and safeguard sensitive business information, the Cisco WAP125 Dubai access point supports both Wi-Fi Protected Access (WPA) Personal and Enterprise, encoding all your wireless transmissions with powerful encryption. In addition, 802.1X RADIUS authentication helps keep unauthorized users out.
The Cisco Wi-Fi Dubai offers a captive portal for guest access, allowing you to control Internet access for guests and give your customers a better experience.
Features:
- Cisco WAP125 Dubai provides cost-effective 802.11ac wireless connectivity for 2.4-GHz and 5-GHz clients with speeds up to 867 Mbps.
- Gigabit Ethernet LAN interface with Power over Ethernet (PoE) enables flexible installation.
- Cisco WAP125 Dubai offers simple web-based configuration and mobile friendly setup wizard allows setup in minutes.
- Cisco WAP125 Dubai supports social media login for guest access (Google and Facebook).
- Cisco Wi-Fi Dubai is integrated with Cisco Umbrella to help manage security across all wireless devices.
- Supported by the new Cisco® FindIT Network Management platform for easy management, monitoring and control your Cisco 100, 300 and 500 access points.
Specifications
| Technical Specification | |
| Cabling | Category 5e or higher |
| Standards | IEEE 802.11ac, 802.11n, 802.11g, 802.11b, 802.3af, 802.3u, 802.1X (secure authentication), 802.1Q (VLAN), 802.1D (Spanning Tree), 802.11i (WPA2 security), 802.11e (wireless QoS), IPv4 (RFC 791), IPv6 (RFC 2460) |
| Antennas | Internal antennas optimized for desktop installation |
| Operating system | Linux |
| Physical Interfaces | |
| Ports | 1 x 10/100/1000 Ethernet, with 802.3af/at PoE support, power port for AC adapter (included) |
| Power supply | 802.3af/at PoE or external 12 V/1 A DC power supply unit |
| Buttons | Reset button, on/off button |
| Lockout socket | Kensington Castle Nest |
| LEDs | One multifunctional LED |
| Physical specification | |
| Physical dimensions (W x D x H) | 123 mm x 123 mm x 31 mm |
| Weight | 303 g |
| Network capacities | |
| VLAN support | Yes |
| Number of VLANs | 1 VLAN manager plus 8 VLANs for SSIDs |
| 802.1X supplicant | Yes |
| SSID-to-VLAN mapping | Yes |
| Automatic channel selection | Yes |
| Spanning Tree | Yes |
| Load balancing | Yes |
| IPv6 |
|
| Layer 2 | VLANs based on 802.1Q, 8 active VLANs plus 1 VLAN to manage |
| Security | |
| WPA, WPA2 | Yes, including Enterprise authentication |
| Access control | Yes, access control list (ACL), MAC ACL |
| Safe management | HTTPS |
| SSID broadcast | Yes |
| Detection of hostile access points | Yes |
| Installation and physical safety | |
| Mounting options | On the desk |
| Quality of Service | |
| QoS | Wi-Fi traffic and multimedia specification (WMM TSPEC), QoS client |
| Performance | |
| Wireless network bandwidth | Data transfer rate up to 867Mbps (actual throughput may vary) |
| Number of users | Up to 64 connected users, 10 active users per radio |
| Configuration | |
| User interface | Built-in web user interface for easy configuration in the browser (HTTP, HTTPS) |
| Management | |
| Management protocols | Web browser, SNMP (Simple Network Management Protocol) v3, Bonjour |
| Remote management | Yes |
| Recording of events | Local, remote syslog, e-mail alerts |
| Network diagnostics | Registration and interception of packages |
| Firmware update | Possibility to update the firmware via a web browser, imported or exported configuration file |
| Dynamic Host Configuration Protocol (DHCP) | DHCP client |
| IPv6 host | Yes |
| Wireless network | |
| Frequency | 2.4 GHz and 5 GHz |
| WLAN |
|
| Supported data rates |
|
| Wireless insulation | Wireless insulation between customers |
| External antennas | None |
| Internal antennas | Internal, fixed PiFA antenna |
| Antenna reinforcement |
|
| Wireless Distribution System (WDS) | Yes |
| Fast roaming | Yes |
| Multiple SSIDs | 8 |
| Wireless VLAN map | Yes |
| WLAN security | Yes |
| Wi-Fi Multimedia (WMM) | Yes, with automatic energy saving |
| Modes of operation | |
| Access point | Access point mode, WDS bridge mode, work group bridge mode |
| Environmental | |
| Power options |
|
| Compatibility |
|
| Operating temperature | 0°C to 40°C |
| Storage temperature | -20°C to 70°C |
| Moisture | 10% to 85%, non-condensing |
| Storage humidity | 5% to 90%, non-condensing |
| System memory |
|
| Package contents |
|
